BACTRON600 16 Cu.Ft.| 453 L, Anaerobic Chamber, 600 Plate Capacity

Get a Quotation

The BACTRON600 Anaerobic Chamber permits volume handling of anaerobic cultures with maximum operator comfort with 16.0 cu. ft. of workspace up to 300-plate with generous stainless-steel shelving and an additional 300-plate capacity side storage incubator. In combination with workspace capacity and side storage incubator capacity, which is designed for high-volume research requiring nominal bench space than expected for the 600-plate volume plus anaerobic performance features. Our BACTRON Anaerobic Chambers have an airtight construction of stainless steel and rigid acrylic glass for unobstructed vision and integrity. The chamber cuffs form a comfortable seal around the operator’s arms that enables complete manipulation of plates and specimens inside the working chamber forming a work user-friendly in most applications. When sitting undisturbed and unopened at a steady state, the BACTRON Anaerobic Chamber typically rests oxygen-free and anaerobic. Our Anaerobic Chambers meet EN61010, UL61010, and Can/CSA61010 standards.

Our BACTRON600 Anaerobic Chamber features:

300-PLATE CAPACITY INNER WORKSTATION WITH STAINLESS-STEEL SHELVING 32.0 X 8.0 in
INTERIOR WORK AREA 42.5 X 28.9 X 25.0 in
300-PLATE CAPACITY ACCESSIBLE SIDE STORAGE INCUBATOR
SIDE STORAGE INCUBATOR AREA 23.5 X 18.5 in
LOW GAS SUPPLY ALARM
INTEGRATED INTERNAL REGULATORS
USER-ADJUSTABLE AIRLOCK CYCLING
AUTO-COMMISSIONING CYCLE 5HRS TO ANAEROBIC
ACTIVATED CARBON/O₂PALLADIUM CARTRIDGE SCRUBBER CATALYST
INTERIOR ELECTRICAL OUTLET FOR LAB INSTRUMENTS
AMG REGULATOR INCLUDED
2-YEAR WARRANTY

Ask us about our Extended Warranties*!

*US Domestic Only

Specs Brochures/Manuals

Model

BACTRON600

Part ID

BAA60022

Exterior Dimensions (W × D × H)

88.5 × 32.5 × 27.6
(2248 mm × 826 mm × 701 mm)

Interior Dimensions (W × D × H)

42.5 × 28.9 × 25.0
(1059.2 mm × 734.0 mm × 635.0 mm)

Volume

16.0 cu.ft. (453 L)

Airlock Capacity

216 Plates

Airlock Dimensions (W × D × DIAG)

16.0 × 10.0 × 11.5
(406.4 mm × 254.0 mm × 292.0 mm)

Shelf Dimensions (W × D)

32.0 × 8.0 (812.0 mm × 203.2 mm)

Unit Weight

412.0 lbs (187.0 kg)

Interior Metal

300 SST

Exterior Metal

300 SST & CR

Operating Temperature Range

Amb +5C - 70C

Temperature Uniformity - Midrange

1.0 °C

Temperature Stability - Midrange

0.2 °C

Controller Type

Digital

Display Resolution

0.1 °C

Power Voltage , Frequency and Current

110-120 VAC, 50/60 Hz, 11.0 Amps

Safety Certifications

UL 61010-1, EN 61010-1, CSA 61010-1, CE
