SMI7 6.5 cu.ft., 184 L | Touch Screen | 110-120 Volt

Get a Quotation

SMI7 SHEL LAB Microbiological Incubator is 6.5 cubic feet (184 L). The unit is perfect for general cell culture and constant temperature applications.

The SHEL LAB Microbiological incubator Series has been redesigned for optimum performance. Ranging in sizes from 2 to 11.7 cu. ft, the SMI Series is guaranteed to fit any workspace need.

NEW – Touch Screen Updates

The SHEL LAB SMI Series touch screen user interface received a complete overhaul!

Now featuring:

Improved real-time clock accuracy
Updated screen color theme from blue to black
New access points for setpoint, alarms, and datalog export
Replaced some text items with screen icons for better clarity

Revolutionizing SHEL LAB’s line of products, the new 7’ inch display makes controlling the SMI units a breeze. With on-screen graphing and real-time data, the SMI’s are at the forefront of incubator technology.

More features of the SMI incubators include:

7” capacitive touch screen usable with laboratory gloves
Real-time clock for logging events
Door alarm
On-screen data graphing
4-20mA output for a chart recorder or central facility recording
Interior outlet
Viewing door
Stainless steel interior
24 month limited warranty

Ask About Our Extended Warranties*!

*US Domestic Only

Spec sheets available for the SMI7 and SMI7-2!

Download the latest SMI Firmware here.
Read our Firmware Update Guide here.

Specs Brochures/Manuals

Model

SMI7

Part ID

SLM722

Exterior Dimensions (W × D × H)

30 × 31 × 32
(762 mm × 787 mm × 813 mm)

Interior Dimensions (W × D × H)

23.7 × 24 × 20
(602 mm × 610 mm × 508 mm)

Volume

6.5 cu.ft. (184 L)

Shelf Dimensions (W × D)

22.8 × 22.8 (579 mm × 579 mm)

Unit Weight

162.0 lbs (73.5 kg)

Interior Metal

430 SST

Exterior Metal

Painted Cold Roll Steel

Operating Temperature Range

Amb +8C - 70C

Temperature Uniformity - Midrange

0.5 °C

Temperature Stability - Midrange

0.1 °C

Controller Type

Digital

Display Resolution

0.1 °C

Power Voltage , Frequency and Current

100-120 VAC, 50/60 Hz, 6.5 Amps

Safety Certifications

UL 61010-1, EN 61010-1, CSA 61010-1, CE
